COMPLETE Scheme of premade bag packaging machine for granules

Various Types Of Host
Stainless Steel Z-Type Material Conveyor
Multi-Head Computer Combination Scale
Stainless Steel Support Platform(optional spray material).
Finished Product Conveyor

Do you need a customized automated packaging solution?

Our professional technicians will contact you after receiving your message

Key Features
Machine Functional Features
  • GMP standard design with international CE certification.
  • Full servo control system for reliable, fast, and accurate execution.
  • Empty bag tracking prevents sealing without bag or filling, saving materials.
  • PLC and large touchscreen central control for simple, convenient operation.
  • Eight and ten station structure with programmable bag movement control.
  • Automatic fault tracking and alarm system with real-time status display.
  • Mechanical empty bag detection: no bag opening, no blanking, no sealing.
  • Variable frequency speed regulation with full cam transmission for stable, low-failure operation.
Full Technical Specifications
Model :
Granule Premade Bag Packaging Machine Specs
Model: MG-GD210
Packaging Speed 80 Bags/Min
Station 10 Station
Packaging Specs L≤360mm, W90-120mm
Weight ≈700kg
Overall Dimension (L*W*H) 1950 x 1400 x 1520 mm
Model: MG-GD250
Packaging Speed 70 Bags/Min
Station 8 Station
Packaging Specs L≤400mm, W130-250mm
Weight ≈700kg
Overall Dimension (L*W*H) 1950 x 1400 x 1520 mm
Model: MG-GD300
Packaging Speed 60 Bags/Min
Station 8 Station
Packaging Specs L≤400mm, W160-300mm
Weight ≈720kg
Overall Dimension (L*W*H) 2100 x 1500 x 1520 mm
Shared Specifications
Packaging Form Premade bags (flat bags, self-supporting bags, zipper bags, handbags, etc.)
Air Source 5-7Kg/m³, 500L/min
Packaging Material Single layer PE, PE composite film, paper film and other composite films
Power Supply 380V
Total Power 7Kw
Applications
Candy Puffed Food Shrimp Chips Potato Chips Popcorn Wolfberry Rice Cracker Fungus Mushrooms Red Dates
