COMPLETE Scheme of vertical packaging machine with measuring cup system for granules

Stainless Steel Z-Type Material Conveyor
Rotary Measuring Cup
Various Types Of Host

Do you need a customized automated packaging solution?

Our professional technicians will contact you after receiving your message

Key Features
Machine Functional Features
  • Imported PLC controls bag length, count, and auto-stop.
  • Dual-zone smart temperature control for horizontal and vertical sealing.
  • Anti-interference photoelectric positioning with dual-bag alarm.
  • Full stainless steel structure meets food and medicine hygiene standards.
  • Cup measuring ensures national standard accuracy for granules.
  • Stepper motor tech guarantees bag forming error under 1mm.
  • Low power consumption with compact space footprint.
  • Fully automated process from measuring to coding and counting.
Full Technical Specifications
Model :
Granule Measuring Cup Vertical Packaging Machine Specs
Model: MG420
Bag Size L 40-300mm, W 50-200mm
Packing Speed ≤80 Bag/Min
Compressed Air 6Kg/m², 0.2m³/Min
Power Consumption 3Kw
Dimensions (L*W*H) 1350 x 1065 x 1450 mm
Weight 350kg
Model: MG520
Bag Size L 80-350mm, W 100-250mm
Packing Speed ≤70 Bag/Min
Compressed Air 6Kg/m², 0.2m³/Min
Power Consumption 3Kw
Dimensions (L*W*H) 1365 x 1160 x 1550 mm
Weight 500kg
Model: MG630
Bag Size L 80-400mm, W 120-300mm
Packing Speed ≤60 Bag/Min
Compressed Air 6Kg/m², 0.2m³/Min
Power Consumption 3Kw
Dimensions (L*W*H) 1700 x 1400 x 1900 mm
Weight 550kg
Model: MG760
Bag Size L 100-450mm, W 150-360mm
Packing Speed ≤50 Bag/Min
Compressed Air 6Kg/m², 0.2m³/Min
Power Consumption 3Kw
Dimensions (L*W*H) 1900 x 1400 x 1900 mm
Weight 750kg
Applications
Almonds Melon Seeds Peanuts Roasted Seeds and Nuts Peas Mixed Nuts Walnuts Dried Lotus Seeds
